Automatically senses generator power and prevents two power sources from entering the ac distribution panel at the same time. Shut down all power sources to the rv label power sources clearly that testing is in progress.
Progressive Dynamics Pd 52v 50 Amp Auto Transfer Switch
Pd52 transfer switch wiring diagram. Pd5000 30 amp acdc distribution panel. It ensures generator outage voltage is stable before powering up appliances plus once the generator is shut down shore power activates after a 3 4 second delay. The progressive dynamics 5200 series automatic transfer switch features rugged heavy duty screw type wiring terminals ready to wire to the contactor base and ensuring easy wiring and preventing wiring errors. That switch was made by progressive dynamics and worked very well so i ordered the progressive dynamics pd52 automatic transfer switch for the 2014 srx. In the 2012 copper canyon i installed an automatic transfer switch. Pd52 240 vac 50 amp automatic transfer switch 240 vac 50 amp switch ac connectors.
Newer models come with an automatic rv transfer switch already installed eliminating the need to have to manually unplug from shore power and plug in the generator. Pd52 troubleshooting youtube video. Pd52 pd52dcs pd52dcsd pd53 owners manual english pd52 pd52dcs pd52dcsd pd53 owners manual french. It is harmful for the transfer switch to switch over power sources while under load. The srx has 50 amp service and the pd52 is designed for 50 amp rv systems. 240 vac 50 amp switch ac connectors.
Troubleshooting the pd52 transfer switch also applies to the pd52p pd52v pd52c pd53. Pd50b pd50k pd5000 connections. Pd52 50 amp transfer switch pd53 100 amp transfer switch. The output of the transfer switch goes to the breaker panels. It is possible to upgrade older models to an automatic 30 amp rv transfer switch which will put everything you need in one single box. Page 8 if the pcbs green led is not illuminated while generator voltage is present indicates the pcb has been damaged and will need replaced.
The trc 50 amp automatic transfer switch is a basic transfer switch that automatically transfers to generator power 30 seconds after generator start up. A time delay circuit board ensures the generator voltage is at a stabile level before the transfer occurs. Progressive dynamics pd52 owners manual. Pd52 pd52c pd52p pd52s pd52dcs pd53. 50amp 240 vac automatic transfer switch pd52. An automatic transfer switch is basically a three way switch that switches between two inputs and connects them to a single common output.
It intercepts the shore power cord feed to the breaker panel. A transfer switch is located prior to the breaker panel.
